High Precision Rapid Prototype 12-Layer PCB - Reliable and Efficient Solutions

11 11,2024

Mingzhenghong Electronics Co., Ltd.

Social interaction

Discover the High Precision Rapid Prototype 12-Layer PCB by Ming Zheng Hong Electronics. Our Rigid PCB (FR-4) delivers exceptional electrical performance with a 135°C TG value and rapid turnaround in just 12 hours. Perfect for CCTV, fire alarm systems, and medical devices.

Introducing Our High Precision 12-Layer PCB

At Ming Zheng Hong Electronics, we take pride in offering top-tier electronic manufacturing solutions, including our High Precision Rapid Prototype 12-Layer PCB. Constructed from FR-4, this Rigid PCB guarantees remarkable electrical performance and mechanical strength. With a TG value of 135°C, it stands out in high-temperature applications, making it an ideal choice for industries ranging from closed-circuit television (CCTV) to fire alarm systems.

Our PCB features precision engineering with a minimum drill hole of 0.4mm and a minimum line width/spacing of just 6mil (0.15mm). It meets stringent IPC-II standards, ensuring reliability and quality across diverse applications. Additionally, the board undergoes a lead-free hot air leveling treatment, providing a robust surface finish that complies with environmental requirements while delivering superior soldering quality.

Key Features of Our 12-Layer PCB

Superior mechanical strength due to FR-4 material.
High TG value of 135°C for excellent thermal stability.
Precision engineering for challenging designs including high-density integrated circuits.
Environmental compliance with lead-free surface treatment.
Quick turnaround within 12 hours for urgent project needs.

This 12-Layer PCB is excellently suited for a wide range of applications, including:

CCTV systems requiring high clarity and stability.
Fire alarm and safety systems needing precise circuit layouts and responsiveness.
Communication devices for prototyping wireless modules and routers.
Medical instruments that require high accuracy and reliability.
Industrial automation for stable performance in control systems.
Automotive industry applications, including sensors and control units, that require quality and durability.

Choose Ming Zheng Hong Electronics as your trusted partner for electronic manufacturing. Our commitment to quality, rapid delivery, and customer satisfaction sets us apart. Contact us today to learn more about our superior PCB solutions!
